Stand Function
1.Common rail injector (include piezo )
2.EUI EUP Test
3.The highest Rail pressure is 2700bar
4.CR injector parts Test :solenoid Valve test ,Openig pressure test, Opening pulse width test
5.CR injector resistance and inductance Test
6.AHE dynamic armature stroke test
7.Test one times injection
8.CR pump test
9.CR pump metering resistance and inductance test
10.Cr pump camshaft sensor resistance and inductance test
11.Cr pump pcv,imv resistance and inductance test
12.Cr Pump Parts Test :ZME,DRV
13.Common rail pipes with filter function
Optional function
1.HEUI testing (can test C7, C9, C-9, 3126, 3408,3412, ISUZU)
2.HEUI actuation pump test
3.CAT 320D Pump Test
4.QR code (DENSO Delphi Siemens Cunnins Bosch and Piezo injector )
Technical parameter:
1. Out put power: 11kw
2. Rotation speed: 0~3000RPM
3. Input power: 380V/50hz/3phase or 220V/60hz/3phase
4. Rail high pressure: 0～2000 bar
5. Test oil filtered precision: 5μ  6. Oil tank: 60L
7. Size: 1.34*0.72*1.53  8. Wight:450kg
