DT-L950 Wheel Loader
Weichai Steyr diesel engine is adopted, with large torque backup and strong power.
Single stage, 4 elements, twin turbo ZL50 torque converter and planetary gearbox from Hangzhou Advance Gearbox Group owns compact structure and high reliability.
Gear-shifting with 2 forward and 1 reverse controlled by flexible shaft eases much labour.
Strengthened axles owning large bearing capacities and high reliability.
Twin pump merging hydraulic system realizes the excellent fuel economy.
The coaxes flow-amplified, hydraulic compensated steering makes operate easy and performace reliable.
Both travel system and working hydraulic system are forced-cooled, improving the efficiency obviously.
Air over hydraulic brake system; Eight caliper disc brakes.
Air break control, expand hoof type parking brake and emergency brake.
Working device with automatically levelling ability at high position.
Main articulated positions take sealed, lubricated, dust-proof layers, which owns good durability.
Integral, luxury dashboard.
New, luxury cabin.
Specification |
DT-L956A |
DT-L956B |
RATD LOAD |
5000KG |
|
OPERATING W. |
16500KG |
|
MAX.DUMP CLEARANCE |
3400MM |
|
DUMP REACH |
1500MM |
|
OVERALL DIM. |
8000X3070X3340 |
|
ENGINE MODEL |
WD10G220 /6CTA8.3-C215 |
|
DRIVE TYPE |
Fixed Shaft Power Shift Trasmission |
|
FRAME |
23.5–25 |
|
Total Cycle Time |
<12S |
|
Standard Bucket |
3.0m3 |
